*Available size: 28”/32”/38”/43”/49”/55”/65”/75”/86”
*Full HD 1920*1080 (28-55 inch), UHD 3840*2160 (55-86 inch)
*High contrast with a view at any angle, colorful display performance
*With network (Android or Windows)–we provide Content Management Software
*Without network (play the content by USB)
*Intelligent Split Screen One screen for multiple purposes
*Free to choose different areas of display content, videos, pictures, text partition play
*Wall-mount type digital advertising signage
This display has brilliant 1080p or 4K picture quality. Amazing visual content resulting in an increase in customer traffic. It can customize templates and set different areas. Can play different images, videos, rolling subtitles at the same time. A cable cover is specially designed on the back plate to protect the power supply and wires. It has three openings for easy routing. The cover can be removed for maintenance by loosening the screws. The cable cover prevents the wires and switches from being damaged, unplugged or touched at will, which effectively protects the machine when it is used in public or unattended commercial space.
*Optional with 10-Finger-Multi Touch Capacitive Touch Panel
*CPU: Rockchip RK3288 Quad Core Processor 1.8Ghz Cortex-A17
*Slim Design with 30mm thickness
*IPS panel for better view angel
*Resolution: 1920×1080
*Optional with customized brightness 300-1000nits
| PC System | |
| CPU | Rockchip RK3288 Quad Core Processor 1.8Ghz Cortex-A17 |
| RAM | Quad Core GPU mail-T764V DDR3 2G |
| Storage | EMMC 8G |
| OS | Android 5.1 |
| LCD Panel | |
| Display active screen size (mm) | 1428×803 |
| Size（inch） | 65″ |
| Backlight | LED |
| Resolution | 1920×1080 |
| Brightness | 350 |
| Aspect ratio | 16:9 |
| Contrast | 1000：1 |
| Viewing angle | 178°/178° |
| Colours displayed | 16.7M |
| Typical reaction time | 8ms |
| Backlight / Backlight Lifetime (hours) | 50,000 |
| Touch Panel | |
| Touch Technology | Capacitive |
| Touch Connector | USB |
| Touch Life (Contacts) | Capacitive ≥50,000,000 |
| Surface | 3mm tempering cover glass |
| Anti-microbial cover glass | Yes |
| Operation/Mechanical | |
| Operating Temperature (°C) | 0℃—50℃ |
| Storage Temperature | -20℃—60℃ |
| Humidity Range (RH) | 5% – 90% |
| Power Supply | AC90-240V, 50/60Hz |
| Power Consumption (W) | ≤198W |
| Dimensions (mm) | 1589x1080x28 |
| External Connectors | |
| 4x TF card | |
| 1x RJ45 | |
| 2x USB | |
| 2xLVDS | |
| 4xRS232 support wifi/bluetooth/3G | |
